HF GV2 RX01 series is two part reaction ink developed for tempered glass. This series is an environmentally-friendly product, the percentage of Chlorine and Bromine is 900ppm and total Halogen is below 1,500ppm. In addition, HF GV3 RX01 series conduct scarcely. It is a three part ink developed for tempered glass.
| Ink type | Three part reaction acrylic ink |
| Features | Gloss finish and excellent in leveling HF GV3 RX01 Series can adhere to glass at low temperature and keep up with the physicality test of every kind. HF GV2 RX01 Series can adhere to glass at low temperature and keep up with the physicality test of every kind. |
| Diluent | T-980 |
| Washup | T-31 |
| Screen Mesh | T-250-420/inch fabric are recommended |
| Mixing ratio | HF GV3 RX01 710, Other colors: A Hardener: CARE 183 = 100:15:2 HF GV3 RX01 120: A Hardener: CARE 183 = 100: 10:2 HF GV2 RX01 710, Other colors: CARE 182 = 100:2 HF GV2 RX01 120: A Hardener: CARE 182 = 100:2 |
| Drying | 120°C x 30min is recommended |
| Notes | • Drying more than 40min at 120°C may help to improve the alcohol resistance. • Please follow the ratio of additive and adjust viscosity with diluents. Once ink is mixed HF GV3 RX01 and additives, the ink will get thicker about three hours at room temperature, so please dilute. • Addition (1%) of CARE 111 to the ink may help to improve the foaming printing problems. • When HF GV3 RX01 Series lose its performance because of the influence of environment and time, please add 1% of CARE 183. • Pot life is approximately 7 hours, so please do not use after 7 hours. • Please check the performance under long storage. |
| Ink | HF GV3 RX01 710 Black |
| Material | Tempered & Thoughted Glass |
| Screen Mesh | T-420/ inch |
| Squeegee | Urethane medium-hard |
| Printing | Hand Printing |
| Mixing Ratio | : HF GV3 RX01 710: A Hardener: CARE183=100:15:2 |
| Diluents | T-980 10% |
| Drying Condition | 120°C x 30min |
