HF PCL Series is single pack reaction ink developed for insert forming on Polycarbonate. The ink can produced good adhesion, flixibility and heat resistance suitable for forming process
| Ink type | single pack polyester ink |
| Finish Gloss | PMMA, PC, ABS, etc |
| Usage | Pattern A 1st layer HF PCL 710 black : T922 = 100 : 20 (60° x 10-30min) 2nd layer HF PCL 125 Pure White : Y3411 = 100 : 20 (60° x 10-30min) 3rd layer HF PCL 800 Medium Clear : Y3411 = 100 : 20 (60° x 3min) Pattern B 1st layer HF PCL 710 black : T922 = 100 : 20 (60° x 10-30min) 2nd layer HF PCL 710 black : Y3411 = 100 : 20 (60° x 30min) |
| Solvent | T-922 (standard solvent) |
| Wash-up | T-31 or T-40 |
| Screen mesh | Tetron or Nylon 200~300 are recommended |
| Drying | 80°C x 30min is recommended |
| Material | Polycarbonate plate |
| Ink | HF PCL 120, 710 |
| Curing | 30 minutes in 60°C, followed by 1 day in room temperature. |
HF SKY-series is a family of two-part reaction inks that is compatable with IMD/IML Application.
| Type | Two part thermal curing ink. |
| Usage | PMMA PC ABS etc. |
| Feature | Gloss finish |
| Diluent | Standard T-980 |
| Mixing ratios | HF SKY 120 White a hardner : A Hardener = 100 : 3 HF SKY 710 : A HARDENER = 100 : 3-10 *if high stretchability is required, less ratio of hardener is better. If there is no requirement of stretchability, high ratio of hardener is better. |
| Washing solvent | T-15 |
| Drying time | 80° x 5min (Temporary drying) 80° x 1-2hours (Final drying after print binder) Example of drying for each layer 1st HF SKY 710 (80° x 5min) 2nd HF SKY 710 (80° x 5min) 3rd HF SKY 710 (80° x 5min) 4th HF SKY 710 (80° x 5min) 5th JT50 Binder (80° x 2hours) Longer drying time give higher heat and wash out resistance |
| Material | Polycarbonate plate |
| Ink | HF SKY 120, 710 |
| Curing | 30 minutes in 60°C, followed by 1 day in room temperature. |
The HF HSD series is a family of two-part reaction type inks. They can be widely applied to various materials, and offer excellent printability. Having a flexible ink layer, they can also be applied in in-mold decoration. This series of inks is halogen-free and environment-friendly.
| Ink type | Polyacrylate-based two-part isocyanate hardener-type. |
| Usage | Excellent adhesion on various materials, suitable for materials such as processed PP, coated surfaces, ABS, PMMA, hard-coated PMMA, PC, processed PET, and aluminium. |
| Features | • Gloss Finish • Widely applicable, demonstrates excellent adhesion to most substrates. • Excellent moisture and solvent resistance. • Halogen-free |
| Diluent | • Standard solvent: T-926 • Slow-dry solvent: T-927 • Retarder: T-980 |
| Mixing ratio | • Ink: D-Hardener = 100:10) • Gel phenomena may occur after 6-8 hours of usage at room temperature after mixing, leading to reduced physical performance. |
| Washup | T-15/T-31 |
| Screen | 200-300 mesh/inch polyester or nylon screens recommended. |
| Drying time | • Sets to touch-dry in 40 minutes at 25°C. • Hard-dries in 1 week (air-drying) or 30 minutes at 80°C+2 days air-drying. • When applied to metal substrates, thermal curing for 20 minutes at 120-150°C is required for optimal results. |
| Notes | • When used on electroplated film, dilute with solutions T-900 or T-910 to prevent solvent attacks to the substrate. (Verification is advised based on substrate differences) • D-Hardener is extremely sensitive to moisture. Use as soon as possible after opening. • Bubbles and/ or pin-holes may form based on printing conditions. Add 1-2% (by weight) of CARE 13 as needed. • Add 3-5% of CARE 73 to enhance adhesion to glass and resistance to boiling and alcohol. |
| Material | Polycarbonate plate |
| Ink | HF HSD 120, 710 |
| Curing | 30 minutes in 60°C, followed by 1 day in room temperature. |
