PID series is two part reaction ink developed for insert/in-mold forming on Polycarbonate, PET, PP etc. The ink can produces good adhesion, flexibility and heat resistance applicable for making a key pad film of mobile phone parts, home appliances, etc.
| Ink type | Two part reaction polyester ink (available for air-drying) |
| Finish | Gloss |
| Usage | Mainly Polycarbonate and PET for insert/in-mold forming Good adhesion, flexibility and heat resistance suitable for forming process |
| Solvent | T-926 (standard solvent) |
| Mixing ratio | PID hardener: by weight Ink: PID Hardener = 100 : 20 *Pot life is about 6~8 hours after mixing with hardener |
| Wash-up | T-905 or T-31 |
| Screen mesh | Tetron or Nylon 250~350 are recommended |
| Drying | 80°C x 30min is recommended |
| Material | Polycarbonate plate |
| Ink | PID120, 710 |
| Curing | 30 minutes in 60°C, followed by 1 day in room temperature. |
